DERAY®-KY 175

Semi-Rigid Thin Wall Kynar® Tubing

The DERAY®-KY 175 Semi-Rigid Thin Wall Kynar® Tubing offers superior protection and insulation for your electrical components. Designed with a 2:1 shrink ratio and an operating temperature range from -55°C to 175°C, this tubing is perfect for high-temperature and harsh environmental applications. It meets several stringent industry standards, including UL 224 125°C VW-1, CSA 22.2 No 198.1 125°C, DEF STAN 59-97 Type 3, BS G198 Part 4 Type 20, VG 95343 Part 5 Type F, QPL SAE AS23053/8, and is CNES approved and listed in the Matrex database.

Crafted from modified PVDF (polyvinylidene fluoride), the DERAY®-KY 175 tubing offers excellent resistance to chemicals and solvents, making it suitable for a wide range of demanding applications in automotive, industrial, aerospace, defense, and mass transit markets. Available in clear, this tubing is designed to provide reliable performance and durability in various environments.

Key features

– Highly flame retardant: Ensures safety in critical applications.

– Semi-rigid and high abrasion resistance: Withstands mechanical stress and cut-through.

– Excellent chemical and solvent resistance: Ideal for harsh environments.

– Versatile applications: Suitable for strain relief and insulation of high-temperature wires.

The DERAY®-KY 175 tubing is designed to meet the highest standards of safety and efficiency, providing dependable mechanical protection and environmental sealing for your electrical components.

DERAY®-KY 175

Interested in our products?

Leave your details, and we'll get back to you:

מתעניינים במוצר שלנו?

השאירו פרטים ונחזור אליכם:

מתעניינים במוצר שלנו?

השאירו פרטים ונחזור אליכם:

Download Datasheet

DERAY®-KY 175 - Semi-rigid Thin Wall Kynar® (-55°C to 175°C, 2:1 Shrink)

Idanim P/N

ORDER NUMBER

EXPANDED

Internal Diameter (min) D

mm (in)

RECOVERED

Internal Diameter (max) d

mm (in)

RECOVERED

Total Wall Thickness (nom) W

mm (in)

DELIVERY UNITS

SPOOL LENGTHS m (ft)

DELIVERY UNITS

1.22 m (48 in)

1-M23053/8-001-C-3/64

0047

1.2 (3/64)

0.6 (0.024)

0.24 (0.009)

300 (984)

25

1-M23053/8-001-C-1/16

0063

1.6 (1/16)

0.8 (0.031)

0.24 (0.009)

300 (984)

25

1-M23053/8-001-C-3/32

0094

2.4 (3/32)

1.2 (0.047)

0.24 (0.009)

300 (984)

25

1-M23053/8-001-C-1/8

0125

3.2 (1/8)

1.6 (0.063)

0.24 (0.009)

300 (984)

25

1-M23053/8-001-C-3/16

0187

4.8 (3/16)

2.4 (0.094)

0.24 (0.009)

300 (984)

25

1-M23053/8-001-C-1/4

0250

6.4 (1/4)

3.2 (0.126)

0.30 (0.012)

300 (984)

10

1-M23053/8-001-C-3/8

0375

9.5 (3/8)

4.8 (0.189)

0.30 (0.012)

150 (492)

10

1-M23053/8-001-C-1/2

0500

12.7 (1/2)

6.4 (0.252)

0.30 (0.012)

100 (328)

10

1-M23053/8-001-C-3/4

0750

19.0 (3/4)

9.5 (0.374)

0.40 (0.016)

50 (164)

10

1-M23053/8-001-C-1

1000

25.4 (1)

12.7 (0.500)

0.50 (0.020)

50 (164)

10
