RSS

Heat-Shrinkable Rain Shed

The RSS Heat-Shrinkable Rain Shed is meticulously crafted to provide exceptional weather protection for outdoor electrical insulations, especially in high-voltage applications. Designed for long-lasting durability, it offers superior resistance to environmental factors such as UV rays, moisture, and temperature variations.

Technical Specifications

  • Material: Advanced heat-shrinkable polymer
  • Shrink Ratio: Adapts tightly around the application area upon heating
  • Weather Resistance: High resistance to UV, moisture, and extreme temperatures, ensuring reliability in outdoor setups
  • Installation: Simplified application process that can be achieved with a standard heat gun for a secure, weather-resistant fit
  • Application: Ideal for enhancing weather protection on high voltage insulators, preventing the accumulation of rainwater and ensuring uninterrupted performance
RSS

Dimension

Available in various sizes to accommodate different insulator types and sizes, ensuring a precise fit and optimal protection against environmental elements.

Ensure your outdoor electrical insulations are protected from the elements with the RSS Heat-Shrinkable Rain Shed, providing superior durability and performance in high-voltage applications.

Interested in our products?

Leave your details, and we'll get back to you:

מתעניינים במוצר שלנו?

השאירו פרטים ונחזור אליכם:

מתעניינים במוצר שלנו?

השאירו פרטים ונחזור אליכם:

Download Datasheet

Idanim P/N

Spec.

As Supplied Inner Diameter (D) (±5) mm

As Supplied Wall Thickness (T) (±20%) mm

After Recovered Inner Diameter (D) Max mm

After Recovered Wall Thickness (T) (±10%) mm

1-Core Rain Shed
I-RSS-RAINSHED-1-35 1-Core Φ 35 35 1.9 17 2.7
I-RSS-RAINSHED-1-40 1-Core Φ 40 40 1.9 24 2.7
I-RSS-RAINSHED-1-50 1-Core Φ 50 50 1.9 24 2.7
I-RSS-RAINSHED-1-60 1-Core Φ 60 60 2.4 32 4.0
I-RSS-RAINSHED-1-70 1-Core Φ 70 70 2.4 32 4.0

3-Cores Rain Shed
I-RSS-RAINSHED-3-45 3-Cores Φ 35 35 1.1 16 2.7
I-RSS-RAINSHED-3-50 3-Cores Φ 45 45 1.1 22 3.0
I-RSS-RAINSHED-3-37 3-Cores Φ 50 50 1.1 22 3.0
